To C:\Program Files\LTC\LTspiceIV\lib\sym\InfineonNMOS Copy LTspiceInfineonNMOSLibrary\sym\InfineonNMOS.Into ~/Library/Application\ Support/Ltspice/lib/sub Copy the contents of the LTspiceInfineonNMOSLibrary/sub folder.Copy the LTspiceInfineonNMOSLibrary/sym/InfineonPMOS folder.Into ~/Library/Application\ Support/Ltspice/lib/sym Copy the LTspiceInfineonNMOSLibrary/sym/InfineonNMOS folder.Download LTspice Infineon NMOS Library.There are no encrypted symbols included unfortunately, but only a handful of Infineon's models use encryption so this is not too big an issue. LTSpice has no problem with PSpice libraries.
When available, it uses their native LTSpice libraries, but when not, PSpice libraries are used. It uses Infineon's publically available libraries, but includes native LTSpice symbols, allowing for easy use and installation. It is missing odd symbols such as power modules, dual MOSFETs, etc. UPDATED August 3rd, 2022: LTspice Infineon NMOS Library is a semi-complete bundle of Infineon's Power N-Channel MOSFETs up to 950V, current as of August 3rd, 2022.
